Checking Tube Welds Before and After Scarfing

Posted by Cameron Serles on Wednesday, December 07, 2016 @ 10:01 AM


The process of tube welding requires several variables to be in check for efficient and stable production and to meet the quality demands of the industry.  Mill dynamics, from setup to production, have an impact on the stability of these variables.  Measuring and monitoring these variables is the first step in controlling them and improving weld quality for tube fabricators.

In response, tube fabricators employ laser based weld inspection systems to monitor a variety of geometrical features around the weld area of the tube and to provide early warning of quality issues related to the welding and forming process.  Traditionally placed right after the weld box on a tube mill, where the majority of tube forming and weld bead measurements can be made, such systems provide the operator with an early warning of weld related process variations that could lead to quality defects.

While most tube mill customers use the system right after the weld box where the most as-weld related information is available, some fabricators use it after scarfing to check for quality issues related to the scarfing process: does the scarfing tool cut too deeply, or not enough?  Is the tool damaged?  Is the scarf cut a consistent amount?  All these questions can be addressed by installing a weld system after scarfing.

Now, Xiris has developed a double head laser based weld inspection system that allows for one head to be placed immediately after the weld box and one head immediately after scarfing.  In this way, tube fabricators can monitor their tube production before scarfing for weld related defects; and after scarfing for potential scarf related issues.



Blog Dec 6.png

WI2000 Double Head Configuration: One Head Post Weld, One Head Post Scarf

 With a double head configuration, tube fabricators can better control their process and improve quality by monitoring the tube profile, weld bead geometry and final scarf cut, all controlled from a single system.



For more information on how Xiris Weld Cameras can help monitor your weld processes, visit Xiris.com or sign up to receive the Weld Video of the Month

Topics: quality control, weld camera, weld inspection, Xiris, Tube and Pipe welding, scarfing, weld seam

Xiris Helps Tube Producer Eliminate Weld Problems

Posted by Cornelius Sawatzky on Wednesday, November 16, 2016 @ 10:08 AM

Xiris’ WI2000 Weld Inspection System measures weld bead and formed tube geometry for tube and pipe producers.  Recently, the WI2000 was featured in an article in the Tube and Pipe Journal, where it was identifed as a major reason why Middletown Tube of Ohio, USA was able to improve its tube quality and reduce its scrap rate.

Providing more benefits than was expected, the WI2000 has helped the tube producer find defects with their mill equipment and setup; catching potential defects before they become failures and cause scrap.  As a result, tube mill setups have become a science rather than an art for Middletown.

Read the full article here.

Blog Nov 16.png

For more information on how Xiris Weld Inspection Systems can improve the quality and productivity of your tube and pipe production, visit Xiris.com

You may also be interested in our Weld Video of the Month

Topics: quality control, weld inspection, Xiris, welding, Tube and Pipe welding, productivity tools, Middletown Tube

Post Scarf Inspection on Tube and Pipe Mills

Posted by Cameron Serles on Tuesday, June 30, 2015 @ 09:54 AM

Scarfing is a process of removing excess weld bead on a pipe or tube to create a desired shape.  It is done by planing longitudinally welded tubes or pipes right after the welding process.  If it is done perfectly, the resulting profile will match the ideal shape of the parent material.  However, if the scarf tool is set to plane too much material, or not enough, the resulting profile could appear too deep or leave a weld bead above the parent material.


Result of a Scarf Tool Cutting Too Deeply


Result of a Scarf Tool Not Cut Deep Enough


Detecting if the scarf tool is properly adjusted is a difficult task to do on a continuous basis.  In particular, some thick walled tube and pipe mills make precision end products using multiple scarf cuts using scarfing tools operating sequentially.  If not correctly adjusted, the tube or pipe could end up with an incorrect profile shapes where the scarf occurred.  A way to make sure that the right amount of material is removed from the welded tube is important.  If placed after the scarfing process on a tube mill, the Xiris WI-2000p can measure the scarf width and bead height left behind after a scarfing process to provide quality control of the scarfing process itself.


Image of an Ideal Scarf Zone from the WI-2000p from Xiris



In the above image taken from a WI-2000p system, a laser profile is shown of a welded tube, post scarf.  The area of the scarfing does not reflect the laser line as well, so the scarfed area can be easily detected and measured.  As the scarf cuts deeper into the material, the scarf width will increase, as it cuts shallower, the scarf width will decrease.

Conclusion

Measuring the scarf area of a tube or pipe with a device such as the WI-2000p Weld inspection system from Xiris is a quality control tool to ensure that the scarfing process has been set properly and not cutting too little or too much of the parent material away.




Would you like to see what the Xiris XVC-1000 has to offer?  Subscribe to the Weld Video of the Month Club to receive exclusive video content recorded by our own XVC-1000

Subscribe Now

 For more information on how Xiris Weld Cameras can help monitor your weld processes, visit Xiris.com

Topics: weld inspection, Tube and Pipe welding, scarfing, WI-2000p
